custom off road 4x4 fabrication custom crossover steering kits

-  DODGE RAM EXTREME DUTY STEERING -

*DESIGN CHANGE IN PROCESS WILL BE READY FOR PURCHASE SOON*

- GRADE 8, 3/4" BOLTS AND NYLOCK NUT'S
- SPECIAL HIGH ANGLE SAFETY WASHERS
- FK, 3-PIECE, TEFLON, 28,000 LB. CHROMO ROD ENDS
- 7/8" SHANK DRAG LINK HEIMS, 3/4" SHANK ON TIE ROD.
- 1.5" X 1/4" WALL DOM  TUBES
- CHROMOLY WELD IN TUBE ENDS

- BENT TO CLEAR SWAYBAR LINKS
- CLEARS LARGER DIFFERENTIAL COVERS




THESE STEERING KITS ARE BEST SUITED FOR 5"-15" OF LIFT, WANTING
ULTIMATE STRENGTH. EACH KIT IS CUSTOM BENT AND BUILT TO A CUSTOM LENGTH, TO MATCH
EACH TRUCKS LIFT HEIGHT AND SUSPENSION COMPONENTS. BEING CUSTOM, MOST KITS ARE
BUILT/SHIPPED IN ABOUT 3-4 WEEKS.

IMPORTANT!

KNUCKLES/PITMAN MUST BE DRILLED TO 3/4" HOLES. STOCK STEERING WILL NOT FIT AFTER!

STEERING STABILIZER WILL HAVE NO PROVISION WITH THIS STEERING. TABS MUST BE
WELDED ON BY THE CUSTOMER, OR A MACHINED CLAMP/MOUNT CAN BE PROVIDED FOR AN
 EXTRA $65

 MUST CHECK THAT THE NEW HEIM ON TOP OF THE PASSENGER SIDE KNUCKLE WILL CLEAR THE
 EXISTING WHEEL. YOU MUST HAVE ENOUGH ROOM FOR A 1.5" DIAMETER 1.75" TALL CYLINDER
ON TOP OF THE EXISTING TIE ROD END NUT. MOST STOCK WHEELS DO NOT FIT WITH THIS
 STEERING.
